The NZXT H9 Flow is a white ATX case with a transparent side panel, visible front and rear cooling fans for airflow, and multiple USB ports on the bottom front edge.
The NZXT H9 Flow is a white ATX case with an angled front-right corner, dual-chamber design for better airflow, and labeled dimensions: 506mm (H) x 481mm (D) x 315mm (W).
The NZXT H9 Flow is a white ATX case with three pre-installed front fans, one rear fan, optimized airflow, and includes F140Q and F120Q three-pin DC fans. Three additional fans are placed outside the case.
The NZXT H9 Flow is a dual-chamber ATX case with labeled spots for radiators and fans, supporting up to 420 mm radiators on top and front, 360 mm on the bottom, and up to ten fans. Text reads Expansive Cooling.
The NZXT H9 Flow case features a spacious interior highlighted in purple, supporting high-performance GPUs up to 435mm for maximum graphics and optimized airflow.
The NZXT H9 Flow ATX case is shown with a dual-chamber design, clearly separating components. Arrows highlight optimized airflow for better cooling and easier cable management. Text reads: “Dual-Chamber Design. Spacious layout boosts airflow and organization.”.
The NZXT H9 Flow is a white ATX case with wraparound glass panels that reveal internal components and cooling fans; text below reads Panoramic Paneling, describing its clear view and airflow optimized for showcasing your build.
The NZXT H9 Flow, a white ATX case with its side panel open, shows a clean dual-chamber design optimized for back-connect motherboards. Purple highlights mark support zones. Text: “Back-Connect Support. Compatible with ASUS BTF and MSI Project Zero.”.
The NZXT H9 Flow is a white ATX case with purple-accented cable channels and straps, featuring a dual-chamber design for easy cable management, wide channels, built-in Velcro straps, and multiple tie-down points.
The NZXT H9 Flow is a black ATX case featuring a transparent side panel, visible cooling fans for optimized airflow, an empty interior, and convenient front panel ports.
The NZXT H9 Flow is a black ATX case with a dual-chamber design, glass panels to showcase the interior and cooling fans, and measures 506mm (height) x 481mm (depth) x 315mm (width).
The NZXT H9 Flow ATX case offers a dual-chamber design for optimized airflow, supports up to ten fans, and accommodates radiators up to 420mm (top/front), 360mm (bottom), and 120mm (rear).
The NZXT H9 Flow, a black ATX case, features three pre-installed F140Q (CV) front-right fans and one F120Q (CV) rear fan for optimized airflow. CV stands for Case Version (3-pin DC).
Close-up of the NZXT H9 Flow ATX case build, showing space for graphics cards up to 435 mm, with a “50 SERIES READY” label. Caption: “H9 Flow: Dual-chamber design optimizes airflow and supports GPUs up to 435 mm.”.
The NZXT H9 Flow is a dual-chamber ATX case featuring wraparound glass panels that showcase internal components and sleek cable management, offering a panoramic view to turn your build into a visual display.
The NZXT H9 Flow is an ATX case with a spacious dual-chamber design that separates heat-generating parts for improved airflow and easier cable management.
The NZXT H9 Flow is a black ATX case with a dual-chamber design and open side panel, optimized for back-connect motherboards. Compatible with ASUS BTF and MSI Project Zero for a clean, cable-free interior.
The NZXT H9 Flow ATX case in black with purple accents is displayed open, highlighting wide cable channels, Velcro straps, tie-down points for easy cable management, and optimized airflow among other features.

H9 Flow

4.3
Rated 4.3 out of 5 stars
4.3 Stars (4 Reviews)
New

大型デュアルチャンバーミッドタワーATXエアフローケース

セール価格$149.99 通常価格$169.99
$20オフ
or
Color:White
The NZXT H9 Flow is a white ATX case with a transparent side panel, visible front and rear cooling fans for airflow, and multiple USB ports on the bottom front edge.
H9 Flow セール価格$149.99 通常価格$169.99

Overview

H9 Flowは、高性能ビルドのために設計された広々としたミッドタワーATXケースで、エアフローと美観のバランスを取っています。デュアルチャンバーデザインは冷却とケーブル管理を改善し、穴あきパネル、角度の付いたファン、十分なファンとラジエーターのサポートにより、最適な熱性能を提供します。

  • デュアルチャンバーデザイン: 主なコンポーネントをPSUとドライブから分離し、熱性能とケーブル管理を向上。
  • 最適化されたエアフロー: 穿孔されたスチールパネルと角度のついた前右ファンが高性能ビルドのための効率的な冷却を保証。
  • 事前インストールされたファン: 前右にF140Q (CV) ファン3つ、後部にF120Q (CV) ファン1つを含む。CV = ケースバージョン (3ピンDC)
  • 10ファン容量: 上部、前右、底部に最大9つの140mmファン、後部に1つの120mmファンをサポート。
  • パノラマビュー:  シームレスでラップアラウンドの強化ガラスパネルでビルドのすべてのディテールを披露。
  • 大型ラジエーターとGPU: 上部と前右に最大420mmのラジエーターを収容し、ハイエンドグラフィックスカードのための十分なクリアランスを提供。
  • 簡単なケーブル管理: 幅広のチャンネル、内蔵のベルクロストラップ、タイダウンポイントでケーブルルーティングを簡単に。
  • バックコネクト対応: ASUS BTFやMSI Project Zeroのようなリア接続マザーボードと互換性があり、ケーブルフリーの外観を実現。
H9 Line up - Built to Flow. Made to Show.

流れるために作られた。見せるために作られた。

H9 Flowは、高性能ビルドのために設計された広々としたデュアルチャンバーケースで、広範な冷却サポートとビルドを一望できるガラスパネルを備えています。
A PC case with RGB lighting, illustrating airflow: blue arrows show cool air entering from the bottom and right, while purple arrows show warm air exiting from the top and left. Temperature display on the CPU cooler reads 32°C.

最適化されたエアフロー

前面右側のファンとエアフロー最適化レイアウトにより、温度を低く保ち、パフォーマンスを安定させます。
Close-up view of a black computer case with a mesh front panel showing two cooling fans inside. The case has a sleek, modern design with sharp edges and a partially visible glass side panel.

メッシュパネル

超微細な高気流メッシュパネルは、埃をフィルタリングしながら気流を最大化します。
Two computer towers: one black with a transparent side panel showing fans, and one white with a clear panel revealing RGB-lit components, liquid cooling, and a digital display inside.

広々としたデュアルチャンバー

発熱するコンポーネントを分離して、エアフローを改善し、クリーンなビルドを実現します。
Side view of a PC case with labeled fan/radiator mounting locations: front (3x120mm/3x140mm), top (3x120mm/3x140mm), bottom (3x120mm/3x140mm), and rear (1x120mm/1x140mm).

10ファン冷却

140mmファンを最大9基、120mmリアファンを1基取り付け可能。

A white gaming PC case with RGB fans and a digital display, showing interior liquid cooling tubes. Purple labels indicate maximum radiator sizes: 420 mm top/right, 120 mm rear, and 360 mm bottom.

ラジエーター大容量対応

上部および前面右側のパネルに最大420mmのラジエーターを取り付け可能で、多様な冷却構成に対応。
Close-up of a computers interior showing an NZXT-branded cooler with a digital display reading 32°C GPU. Purple overlay text reads Up to 435mm. Bottom right has a green label: 50 Series Ready.

マキシマムグラフィックス

435mmまでのGPUに対応し、ハイエンドグラフィックスカードに十分なスペースを提供します。
Open white computer case showing interior with highlighted motherboard tray and cable management sections in purple gradient. Multiple cable routing channels and mounting points are visible.

バックコネクト準備完了

ASUS BTFおよびMSI Project Zeroマザーボードに対応し、ケーブルのない外観を実現。

A black NZXT computer case with its side panel open, revealing an empty interior and highlighted mounting areas. A circular inset zooms in on an internal NZXT-branded strap.

簡単なケーブル管理

超広幅のチャンネル、ベルクロストラップ、固定ポイントにより、ケーブル配線が簡単になります。
Tech Specs
高さ
506 mm（19.9インチ）
幅
315 mm（12.4インチ）
奥行き
481 mm（18.9インチ）
容積
76.7 L
重量
12.46 kg（27.47ポンド）
エンクロージャタイプ
ミドルタワー
マザーボード互換性
E-ATX（最大277 mm）、ATX、Micro-ATX、Mini-ITX
背面接続式マザーボードサポート（BTF、Project Zero）
対応（ATX、Micro-ATX）
材質
SGCCスチール、透明強化ガラス（白）、着色強化ガラス（黒）
CPUクーラーの高さ
165 mm
GPUの長さ
最大459 mm（厚さ56 mm未満のファンをフロント右に取り付けた場合） 最大410 mm（厚さ56 mmの420 mm AIOとファンをフロント右に取り付けた場合）
PSUの長さ
200 mm
トップラジエーターとファンの厚さ
最大80 mm（360 mm） 最大62 mm（420 mm）
USB 3.2 Type-A
2
USB 3.2 Gen2x2 Type-C
1
ヘッドホンジャック
1
標準
7
垂直
0
2.5インチ
4+2
3.5インチ
2
フロント右
3 x 120 mm / 3 x 140 mm（3 x F140Q (CV) を含む）
トップ
3 x 120 mm / 3 x 140 mm
ボトム
3 x 120 mm / 3 x 140 mm
リア
1 x 120 mm（1 x F120Q (CV) を含む）
フロント右
最大420 mm
トップ
最大420 mm
ボトム
最大360 mm
リア
最大120 mm
モデル
F140Q (CV)
スピード
1,350 ± 150 RPM
風量
100.25 CFM
静圧
1.4 mm-H₂O
ノイズ
22.9 dBA
ファンコネクタ
3ピン
モデル
F120Q (CV)
スピード
1,350 ± 150 RPM
風量
60.2 CFM
静圧
1.05 mm-H₂O
ノイズ
24.1 dBA
ファンコネクタ
3ピン
保証
2年
型番
CM-H92FW-01 CM-H92FB-01
UPC
810074847841 810074847858
EAN
5056547207636 5056547207643
4.3
Rated 4.3 out of 5 stars
Based on 4 reviews
100%would recommend this product
Total 5 star reviews: 1 Total 4 star reviews: 3 Total 3 star reviews: 0 Total 2 star reviews: 0 Total 1 star reviews: 0
Product QualityRated 5.0 on a scale of 1 to 5
Value for MoneyRated 4.5 on a scale of 1 to 5
Write a Review (Opens in a new window)
4 reviews
  • KG
    Kristoffer G.
    Verified Buyer
    I recommend this product
    Product Standouts Ease of use
    Rated 4 out of 5 stars
    Aug 8, 2025
    Great product - instructions could be better

    Very roomy case so the design is is better than the H7 I ordered for another project.

    Some minor nitpicks.

    The NZXT 420 radiator could not fit on the front but was fine on the top. The actual radiator fits but the extrusion for the hoses does not in the front position. Strange that they say 420 will fit but not their own. I used the front slot for a GPU water cooler so all is good. I also have the lighting hub but I only noticed after installing the motherboard that the tightening screws are under the motherboard so a sticker there would have helped and save time. Only last thing the motherboard screws were a bit flimsy so I used my own.

    Overall once you done the build the end result is great.

    Product QualityRated 5.0 on a scale of 1 to 5
    Value for MoneyRated 4.0 on a scale of 1 to 5
    Was this helpful?
  • CB
    Christopher B.
    Verified Reviewer
    I recommend this product
    Product Standouts Great Quality, Ease of use, Design, Value for Money
    Rated 4 out of 5 stars
    Jul 28, 2025
    Beautiful case.

    Upgraded from the original H9 — and the improvements are obvious.

    Cable management was already top-tier in the previous model, but NZXT has enhanced it further. There’s noticeably more space behind the motherboard tray, and the upgraded Velcro straps are now wider and more secure.

    The case is rear motherboard compatible, which was a key selling point for me and a major step forward for future-proofing. It also supports 420mm radiators, offering more room than ever for advanced cooling setups.

    One standout improvement is the cutout at the top, which allows you to route your AIO tubes cleanly and efficiently. It’s a simple addition, but a huge win for cleaner builds and less strain on tubing.

    Build quality across the board is excellent: tool-less latches, thumb screws, removable dust filters, and magnetic panels make everything more convenient. And if you’re using NZXT RGB fans, the RGB variant of the case includes them pre-installed, which means you don’t need to buy extra fans — a huge value add.

    One drawback: Lian Li Infinity fans don’t fit properly on the rear exhaust. I saw others on Reddit grinding the fan frame to make them fit, but I wasn’t willing to do that. I ended up force-fitting the fan, which isn’t ideal due to the pressure it puts on the frame and lighting elements — but it looks clean.

    Final recommendation: NZXT should revise the rear exhaust mount to better accommodate a wider variety of fans. This issue existed in the previous H9 Flow as well — it’s…

    Product QualityRated 5.0 on a scale of 1 to 5
    Value for MoneyRated 4.0 on a scale of 1 to 5
    Was this helpful?
  • RT
    Ryan T.
    Verified Buyer
    I recommend this product
    Product Standouts Great Quality
    Rated 4 out of 5 stars
    Jul 22, 2025
    Great Chassis w/ minor nit

    I understand why the buttons were moved to the bottom and love the airflow improvements that opened up. But I really miss the I/o ports and power button being more accessible. Little nit pick but everything else about this chassis is amazing.

    Product QualityRated 5.0 on a scale of 1 to 5
    Value for MoneyRated 5.0 on a scale of 1 to 5
    Was this helpful?
  • CS
    craig s.
    Verified Buyer
    I recommend this product
    Product Standouts Great Quality, Value for Money, Ease of use, Design
    Rated 5 out of 5 stars
    Jun 24, 2025
    Beautiful and functional

    Case does exactly what it's designed to do, maximize airflow and look stunning. Easy to build in and cable manage.

    Product QualityRated 5.0 on a scale of 1 to 5
    Value for MoneyRated 5.0 on a scale of 1 to 5
    Was this helpful?
